| AVR-FC3 Silicone Coated Circuit |
|
Features
1. Single phase full wave control using SCR
2. No relay and transformer – less fault rate
3. Parallel operation
4. Dust-resistant and anti humid by silicon coated circuit
5. Controllable by external machine
6. Low frequency protection circuit included
7. Can set output over voltage protection
8. Generator capacity selection switch included
9. May have low exciter relay resistance
Specifications
1. Output : 125Vac, 10A
2. Power Input : 1P 220Vac(180~270)
50/60/125Hz, 1.2KVA
3. Sensing Input : 1P 180~270Vac, 300~450Vac, 50/60Hz, 8VA
4. Overall(mm) : W135 * H150 * D45
5. Weight(kg) : 1.35
6. Operating Temp : -20~70℃
|
| |
|
|
| AVR-FC1 |
|
Features
1. Single phase full wave control
2. Parallel operation
3. Generator capacity selection switch included
4. 50/60Hz selection switch included
5. Low frequency protection circuit included
6. Over excitation block circuit included(output over voltage)
7. Can control voltage by other control machine
8. Semiconductor protection fuse – spare fuse
9. Can accept input power from PMG or secondary coil power supply
Specifications
1. Output : 125Vdc, 10A
2. Power Input : 1P 220Vac(180~270), 50/60/125Hz, 1.2KVA
3. Sensing Input : 1P 180~270Vac, 300~450Vac, 50/60Hz, 8VA
4. Overall(mm) : W140 * H200 * D40
5. Mounting Holes(mm) : W90 * H190 / 5Ф * 4Holes
6. Weight(kg) : 1.35
7. Operating Temp : -20~70℃
|
|
|
|
| AVR-FC2 |
|
Features
1. Single phase half wave control
2. 50/60Hz selection switch included
3. Generator capacity selection switch included
4. Low frequency protection circuit included
5. Over excitation block circuit included(output over voltage)
6. Anti vibration and anti humid by silicon coating
7. Can accept input power from PMG or secondary coil power supply
Specifications
1. Output : 125Vdc, 6A
2. Power Input : 1P 220Vac(190~277), 50/60/125Hz, 1.2KVA
3. Sensing Input : 1P 180~277Vac, 50/60Hz, 8VA
4. Overall(mm) : W140 * H200 * D36
5. Panel Cut-out(mm) : W90 * H190
6. Weight(kg) : 1.35
|
|
|
|
| AVR-638 Over voltage Detection |
|
Features
1. Single phase half wave control
2. Steel case – after-salse service available
3. Generator capacity selection switch included
4. Low frequency protection circuit included
5. Over voltage detection circuit included
6. No relay and transformer – less fault rate
7. Over excitation circuit included
(output overvoltage)
8. Stable operation within low remaining voltage
Specifications
1. Output : 63Vdc, 5A
2. Power Input : 1P 220Vac(190~277), 50/60Hz
3. Over excitation block : when excitation voltage is over 85±5Vdc or 100±5Vdc at an instant
4. Overall(mm) : W100 * H160 * D40
5. Mounting Holes(mm) : W60 * H150 / 5Ф * 4Holes
6. Weight(g) : 520
7. Operating Temp : -20~70℃
|
| |
|
|
| AVR-635 Normal Output |
|
Features
1. Single wave half wave control
2. Steel case – after-salse service available
3. Generator capacity selection switch included
4. 50/60Hz selection switch included
5. Low frequency protection circuit included
6. Over excitation block circuit included
(output over voltage)
7. Stable operation within low remaining voltage
Specifications
1. Output : 63Vdc, 5A
2. Power Input : 1P 220Vac(190~277), 50/60Hz
3. Sensing Input : 1P 190~277Vac, 50/60Hz
4. Overall(mm) : W100 * H160 * D40
5. Mounting Holes(mm) : D60 * W150 / 5Ф * 4Holes
6. Weight(g) : 520
|
|
|
|
| AVR-631 Large Output |
|
Features
1. Single phase half wave control
2. Aluminum case – afer-sales service available
3. Generator capacity selection switch included
4. 50/60Hz selection switch included
5. Low frequency protection circuit included
6. Over excitation block circuit included
(output over voltage)
7. Stable operation within low remaining voltage
Specifications
1. Output : 63Vdc, 10A
2. Power Input : 1P 220Vac(190~277), 50/60Hz
3. Sensing Input : 1P 190~440Vac, 50/60Hz
4. Overall(mm) : W100 * H160 * D40
5. Mounting Holes(mm) : W60 * H150 / 5Ф * 4Holes
6. Weight(g) : 530
|
|
|
|
| AVR-63P |
|
Features
1. Single phase half wave control
2. Anti vibration and anti humid by silicon coating
3. Generator capacity selection switch included
4. 50/60Hz selection switch included
5. Low frequency protection circuit included
6. Over excitation block circuit included
(output over voltage)
7. Stable operation within low remaining voltage
Specifications
1. Output : 63Vdc, 5A
2. Power Input : 1P 220Vac(190~277), 50/60Hz
3. Sensing Input : 1P 190~440Vac, 50/60Hz
4. Overall(mm) : W100 * H160 * D39
5. Mounting Holes(mm) : W60 * H150 / 5Ф * 4Holes
6. Weight(g) : 520
|
|
|
|
| AVR-126 |
|
Features
1. Single phase full wave control
2. Can accept input power from PMG or
secondary coil power supply
3. Parallel operation
4. Low frequency protection circuit included
Specifications
1. Power Input : 1P 220Vac, 60Hz
2. Sensing Input : 220/380Vac
3. Max Series Output : 125Vdc, 28A or 36A
4. 1 min Using Output : 180Vdc, 20A
5. Oveall(mm) : W140 * H200 * D60
6. Mounting Holes(mm) : W90 * H190 / 5Ф * 4Holes
7. Weight(kg) : 2
|
|
|
|
| AVR-CT1 |
|
Features
1. Single phase half wave control using SCR
2. Parallel operation
3. Low frequency protective circuit included
Specifications
1. Output : 63Vdc, 10A
2. Power Input : 3Phase 220Vac
3. Overall(mm) : W130 * H160 * D53
4. Mounting Holes(mm) : W60 * H150 / 5Ф * 4Holes
5. Operating temp. : -20~70℃
6. Weight(g) : 700
|
|
|
| AVR-SM5 |
|
Features
1. Switching control
2. Can accept power input via PMG or secondary coil
3. Parallel operation
4. Low frequency protection circuit included
5. Designed for over current protection
6. Voltage controllable from separated device
7. LAM ability
8. Generator capacity selection switch included
Specifications
1. Output : Consecutively 77Vdc, 5A
2. Power Input : 1P 110Vac, 50/60/125Hz, 800VA
3. Sensing Input : 1P 110/220/380Vac, 50/60Hz, 5VA
4. Dimensions(mm) : W140 * H200 * D50
5. Mounting Holes(mm) : W90 * H190 / 5Ф * 4Holes
6. Weight(g) : 700 |
